---About product

   Our Saw-tooth Wave Jig is a new type of energy saving and high efficient gravity separation equipment and developed based on the traditional Sine Wave Jig. The difference between Saw-tooth Wave Jig and Sine Wave Jig is that the pulsation curve for jigging is saw-tooth wave shape, with speedy upward flow and slow downward flow. Bed layer is elevated integrally and slowly dropped with a long effective loose time, allowing significant increase of handling capacity.
for unit screen surface,decrease of lower limit of grain size recovery and large save of make-up water for under size fraction.In practice, contrast of Saw-tooth Wave Jig and Sine Wave Jig shows up raises of recovery of Saw-tooth Wave Jig: Sn:3.01%, W:5.5%, Pb:1.63%, Zn:2.04%.

---Working principle
Jig machines need water to work, and it loosens materials in vertical alternative water-flows, and it forms different layers of materials of different densities and discharges both layers from up and down discharging ports separately. The basic composition of jigger is jigging chambers, also called jigging boxes, and there are screens in each chamber.

---Main Features

1. High capacity
2. High concentration ratio and high recovery
3. Fabricated with highest quality material
4. Easy to install, operate and maintain
5. The pulsation curve is saw-tooth wave shape facilitate heavy mineral to settling
6. Saving water 30-40% than ordinary jig
7. The pulsation speed very easy adjusted by regulator
8. Suitable for roughing and desliming
9. Can achieve a good result in processing such as placer gold, tungsten, iron, tin,
hematite, cope, tantalum-niobium, titanium, manganese, barite, zirconium, chrome and gemstone etc.
---Technical parameter
